GoodCut Handheld Einscan Pro 2x 2020 3d Scanner

Handheld 3d scanner
Einscan pro 2x 2020
LED light source
High precision
Product description: Einscan Pro 2x 2020 High speed and high preicison

Iquiry

Contact

Product Description

GoodCut Handheld Einscan Pro 2x 2020 3d Scanner

Model	Einscan Pro 2x 2020
Scan Mode	Handheld HD Scan	Handheld Rapid Scan	Fixed Scan with Turntable(with Add-on: Industrial Pack)	Fixed Scan without Turntable(with Add-on: Industrial Pack)
Scan Accuracy	up to 0.045 mm	up to 0.1 mm	0.04 mm(single shot accuracy)	0.04 mm(single shot accuracy)
Volumetric Accuracy*	0.3 mm/m (Markers Alignment)	0.3 mm/m (Markers Alignment)	/	/
Scan Speed	10 fps 3,000,000 points/s	30 fps1,500,000 points/s	Single Scan＜1s	Single Scan＜1s
Point Distance	0.2 mm-2 mm	0.2 mm-2 mm	0.16 mm	0.16 mm
Single Scan Range	150120 mm — 250200 m
Depth of Field	±100 mm
Working Distance	400 mm
Light Source	LED
Align Mode	Marker Alignment,Feature Alignment [3],Hybrid Alignment [4]	Marker Alignment,Texture Alignment [2],Feature Alignment [3],Hybrid Alignment [4]	Turntable Coded Targets, Feature, Markers, Manual Alignment	Markers, Feature, Manual Alignment
Texture Scan	Yes (with Add-on: Color Pack)	Yes (with Add-on: Color Pack)	Yes (with Add-on: Color Pack)	Yes (with Add-on: Color Pack)
Outdoor Operation	Set up the shelter or cover to avoid direct sunlight
Special Objects for Scanning	For the transparent, highly reflective or some dark objects, please spray powder before scanning
Printable Data Output	Able to export watertight 3D model directly to 3D printing
Output Formats	OBJ; STL; ASC; PLY; P3 ; 3MF
Scanner Body Weight	1.13kg (include the USB3.0 cable)
Supported OS	Win7; Win8; Win10; (64bit)
Recommended Configuration	Graphics card: NVIDIA GTX/RTX series cards, higher or equal to GTX 1080；video memory: ≥4G; processor: I7-8700 or higher; memory: ≥64G; interface: high-speed USB
Required Configuration	Graphics card: Quadro card P1000 and above or NVIDIA GTX660 and higher; processor: Intel (R) xeon E3-1230, Intel (R) I5-3470, Intel (R) I7-3770; interface: high-speed USB 3.0; memory: 8G
[1]. Volumetric accuracy refers to the relationship between 3D data accuracy and object size; the accuracy is reduced by 0.3mm per 100cm. The conclusion is obtained by measuring the center of sphere under marker alignment.[2]. This alignment needs Color Pack assisting, and requires rich color texture information on the surface of the object.[3]. Select this alignment when scanning objects with rich geometrical features on the surface.[4]. Hybrid alignment means marker alignment and feature alignment can be switched automatically.SHINING 3D reserves the right to explain any alteration of the specifications and pictures. Please refer to einscan.com to find more info
